ZGTEK "Cage welding machine line" is used to make filter bagcages, which used in dust collector (baghouse) to support filterbags / bag filters. ZGTEK is aprofessional manufacturer, only focus on manufacturing cage weldingmachine line and developing the technologies.

Machine’sfeature: CNC control; Ring spaceis programmable and cage is pulled by step motor; Ringspace precision is 0.1mm; Pulling speed is 0.4m/s.

ZGTEK provides leading technologies infilter bag cage welding industry, from a stand alone machine to a whole automatedline, with world class flexibility, quality and cost-efficiency.

1. The six machines are basicconfiguration of a cage welding line.

1) 16 or 24-vertical wires cagebody welding machine DLN-24/DLN-16,

2) Ring making machine R-6-300/ RM-6-310,

3) Air-operated butt weldingmachine UR-40,

4) Top collar welder forfilter cage DS-80,

5) Bottom cap welder forfilter cage DX-80,

6) Wire straightening machineTZ2.8-5,

1. Type of cage: Round cage, Oval(flat) cage, Star cage, Split cage, etc.

     Cagesize: OD100-200mm

     Material: Mild steel wire, Stainless steelwire, Galvanized carbon steel wire, Titanium steel wire, etc.

     Sizes of steel wire: 2.8-6mm



   3. Requirements of one completeproduction line:

   1) Workshop area: 10m*20m

   2) Power capacity: 45-50KVA

   3) Workers: 5 people for arunning line



   4. Output

   For example: Filter cage: 24vertical wires * 6000mm Length, Ring distance: 50-200mm.

   Daily output: 25pcs/hour, 250pcs (10hours/day)

   Annual output: 70000pcs (280days)



   ZGTEK is well-known as the “Expert of cagewelding technologies”, is very famous not only inChina, but also all over the world for its highlight performance, like, fast speed, stable, easy-operating, low maintenance, long life, mostimportantly, produce good quality cages, etc.



   ZGTEK cage machines have been used by more than95% Chinese cage makers & have been exported to over 40 countries in different continents, likeEurope, South and North Americas, Asia, Middle East, Africa, etc.



   For more information, please feelfree to contact us. Warmly welcome your honored company to come and visit us atyour earliest convenience.  (P.S. ZGTEK is only 80KM away from Shanghai city, takes only 1.5hr bycar)
