Price:Negotiable
Model:YS-SS-600

Send Inquiry

The SS woven wire is 150-600 mesh as the excel show,the

Woven patterns applied for stainless steel wire mesh or wire cloth can be plain weave, twill weave, Dutch plain weave or Dutch twill weave, while square woven wire mesh is made by either plain weave or twill weave. Woven wire mesh with equal mesh count horizontally or vertically has square opening, hence also called square opening wire mesh, or single layer wire mesh.

Material: Stainless steel wire SUS304, SUS304L, SUS316 or SUS316L for stainless steel woven wire mesh and cloth.
We can supply you with High number of mesh,from 150 mesh to 600 meshThe specification as follow in excel:

SR     NO	MESH	GAUGEEGEGE	WIRE DIA IN MM	APERTURE/OPENING IN MICROS	WT/SQ MTR KGS	WEAVE	%OPEN AREA
1	150	45	0.07	99	0.362	Plain	34.41
2	150	45.5	0.063	106	0.294	Plain	39.43
3	150	47	0.05	119	0.185	Plain	49.66
4	170	45.5	0.063	86	0.333	PLAIN	33.45
5	170	47	0.05	99	0.21	PLAIN	44.27
6	200	47	0.05	77	0.247	PLAIN	36.76
7	240	47	0.05	56	0.296	PLAIN	27.83
8	250	48	0.04	62	0.197	PLAIN&	36.76
						TWILL
9	300	48	0.04	45	0.237	TWILL	27.83
10	300	49	0.03	55	0.133	PLAIN&	41.69
						TWILL
11	320	49	0.03	49	0.142	TWILL	38.69
12	325	48	0.04	38	0.256	TWILL	23.83
13	325	48.5	0.035	43	0.196	TWILL	30.49
14	325	49	0.03	48	0.144	PLAIN&	37.96
						TWILL
15	400	49.5	0.028	36	0.155	TWILL	31.25
16	400	50	0.025	39	0.123	TWILL	36.76
17	500	50	0.025	26	0.154	TWILL	25.79

We can supply it with the mesh from 150 to 600 mesh,The wire diameter and other details are different,We can accordingly to requirment to produce it.



 Wire Mesh Packing: wrapped with moister-proof paper, then in wooden cases
