RG6(17VATC)
DEscriptION
Conductor: 1.13 CCS
Dielectric: 4.8 mm Foam polyethylene
First Shield:AL/P/AL
Second Shield: Aluminum or Copper wire braid 45% coverage
Jacket: 6.8 mm white PVC
APPLICATION
Used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.


RG6/U Satellite cable
DEscriptION
Conductor: 1.02 Bare copper
Dielectric: 4.7 mm 5 Cell PE
Shield: Bare copper braid 45% coverage
Jacket: 6.8 mm black PVC
APPLICATION
Used as a distribution cable for indoor CATV, CCTV systems and as a connection cable for satellite systems where lower attenuation required.
