Model:FZH1012/FZH1212/FZH1512
Send Inquiry
Equipment Features:
The machine processes welding operations for the end, branch, and flange of steel tube. at both ends of the worktable, it install with two sets of T-slots with self-centering, three-jaw chuck (including a set can move in the range of 11 meters), to ensure the flange is vertical with the pipe, and the exact positioning of connection of the flange screw.
Main Technical Specifications:
Model | FZH1012 | FZH1212 | FZH1512 |
Function | Flange welding of steel tube nodes | ||
Diameter of the flange(mm) | Φ250~Φ1000 | Φ250~Φ1200 | Φ250~Φ1500 |
Center height(mm) | 800 | ||
Length of steel tube(mm) | 12000 | ||
Size of branch tube flange(mm) | Φ150~Φ700 | ||
Rotation angle | ±60° | ||
Move speed(mm/min) | 10000 | ||
Motor power(kW) | 1.1×2 | ||
Dimension(mm)(LxWxH) | 16900x1700x2600 | 16900x2100x3000 | 16900x2700x3600 |
