Model:HHh-120
Industrial heat exchanger for telecom cabinet cooling
Description:
HHh series uses patented technology, integration of superconducting heat pipe technology and micro-channel heat transfer technology, the perfect combination of both, to achieve excellent heat transfer performance.
Scope:
1. Widely used in telecommunication, broadcasting, electricity, automation and other industries outdoor cabinet, IDC room cooling needs.
2. Using natural cooling technologies, energy efficient operation, more reliable than air-conditioning, lower cost.
3. Completely solved dust and moisture contamination issues caused by ventilation.
Feature:
AC,DC optional for various application
Multiple protection function
Alarm output to monitoring system
Interchangeable and visual display service adapter
Automatic self start after power recovery
Remote control through RS485comm. port
Speed controller for AC,DC models reduces Noises, increases life and saves energy.
Integration of superconducting heat pipe technology and micro-channel heat transfer technology, the performance is excellent.
Proper design for easily installation and service.
Parameter:
| Items | Unit | Description | Models(HHh-120) |
| Cooling Capacity | W/K | 120 | |
| Heater | W | Option | 500,800,1000 |
| Air Flow | stere/h | Internal air flow | 720 |
| Fan type | Backward Centrifugal Fan | ||
| Temp. | degree | operation range | -40-60degree 0-90%RH |
| Noise | dB(A) | 3m,away ETS300-753 | 55 |
| dimension | mm | W*H*D | 450*1172*200 |
| Weight | Kg | Net Weight | 24 |
| Power Consumption | W | DC:48V AC:230V/110V | 148 170 |
| Power Supply | V | Rated | 24v,48v,230v/110v,50/60HZ |
| IP grade | IEC6052 | >=Ip55 |
