Model:yc2
Send Inquiry
| Power kW | Power generator unit model | Voltage V | Current A | Fuel consumption L/h | Power generator unit net weight kg | Power generator unit size L×W×H mm | YuChai diesel engine model | Generator | Flywheel shell characteristics | Flywheel characteristics | |
| Model | Productor | ||||||||||
| 24 | 24GF96-4 | 400 | 43.3 | 7.6 | 900 | 1800×750×1100 | YC4108D(D7200) | BCI184G14 | the new age / stamford | SAE3 | SAE11.5 |
| 30 | 30GF104-1 | 400 | 54.1 | 9.5 | 930 | 1880×750×1100 | YC4108D(D7200) | BCI184H14 | the new age / stamford | SAE3 | SAE11.5 |
| 40 | 40GF48-1 | 415 | 69.6 | 12.7 | YC6105D(1644A) | UCI224D14 | the new age / stamford 415V | SAE2 | SAE11.5 | ||
| 68 | 68GF | 400 | 122.7 | 20.9 | 1400 | YC6108ZD(B7102) | UCI224G14 | the new age / stamford | SAE2 | SAE11.5 | |
| 80 | 80GF1-6 | 415 | 139 | 24.4 | 1500 | 2450×980×1400 | YC6108ZLD(B7203) | UCI274C14 | the new age / stamford 415V | SAE2 | SAE11.5 |
| 160 | 160GFZ | 400 | 289 | 43.5 | 2160 | 2720×1040×1600 | YC6M260D(M7900) | UCI274H14 | the new age / stamford,automation | SAE1 | SAE14 |
| 200 | 200GF79 | 400 | 361 | 53.7 | 2400 | 2980×1040×1600 | YC6M320D(M7600) | HCI444C1 | the new age / stamford | SAE1 | SAE14 |
| Explanation: in addition to the special note, all the rating of the generator frenquency for frequency 50Hz, rated power factor of 0.8Z(lag), the rated speed for 1500 r/mi, phase number is 3 phase. |
