| Technical parameter of HPZK-70/2 Hollow Plastic Moulding Machine | ||
| Specifications | ||
| Max container capacity | L | 20 |
| Size | M | 4X2.6X2.7 |
| Total weight | ton | 4.5 |
| Clamping Unit | ||
| Clamping force | KN | 180 |
| Platen opening stroke | mm | 250-800 |
| Max mould size | mm | 480x500 |
| Mould thickness | mm | 250-400 |
| Power | ||
| Max drive | kw | 7.5 |
| Total power | kw | 40 |
| Fan power forscrew | kw | 0.18 |
| Air pressure | Mpa | 0.7 |
| Air consumption | m3/min | 0.9 |
| Average energy consumption | kw | 20 |
| Extruder unit | ||
| Screw diameter | mm | ф70 |
| Screw L/D ratio | L/D | 25:01:00 |
| Plasticsing capacity | kg/hr | 80 |
| Number of heating zone | zone | 4 |
| Extruder heating power | kw | 10 |
| Extruder driving power | kw | 18.5 |
| Die | ||
| Number of heating zone | zone | 3 |
| Power of die heating | kw | 4 |
| Max die-pin diameter | mm | 250 |
| Accumulator capacity | ml | 2000 |
we can offer many series of Hollow Plastic Moulding Machine,please contact with us to negotiate about price of HPZK-70/2 Hollow Plastic Moulding Machine.
