Model No.:BLB80PC
Product Origin:China
Brand Name:BAILONG
Price Terms:FOB, CIF
Payment Terms:T/T, L/C
Certification:CE, ISO9001
Description:Features: 1) Control system: Mitsubishi PLC, imported HMI, temperature controller, imported electronic parts 2) Hydraulic system: imported valves, proportional control 3) Power: automatic control, high efficiency, low power consumptionSpecifications: 1) Machine model: BLB65/D2) Max. product capacity: 5L3) Output (cycle time): 300/480pc/h4) Extruding system:a) Screw diameter: 65mmb) Screw L/D ratio: 24c) Extruding power: 18.5kWd) No. of heaters: 3e) Screw heating power: 11.1kW5) Clamping system:b) Clamping force: 57KNc) Platen size: 290x 360mmd) Platen opening stroke: 150 - 500mme) Max. mould size: 350 x 360mm7) Power:a) Mould thickness: 155 - 300mmb) Total power: 42.5kWc) Average power consumption: 26kWd) Air pressure: 6Bare) Air consumption:0.4/0.8m3/minf) Cooling water consumption: 3 Barg) Cooling water consumption: 3/68) Machine dimensions: 3.4 x 2.2 x 2.5m9) Machine weight: 3.7T
