Main application:
The V Type High Efficient Mixer is used for mixing of dry granulate material in pharmaceutical,food-stuff, chemical and other industries.

working principle:
Featuring unique structure, high mixing Function and uniform mixing, the mixing barrel is made of stainless with polished internal and external walls. And this machine has beautiful appearance, uniform mixing and wide application.

Technical Parameters:

Specificatio (m3)	Capacity (L)	Rotorspeed r.p.m	Power (kw)	Overall dimesions (mm)	Net weight (kg)
0.005	2	15	0.095	300*400*600	25
0.05	20	15	0.37	950*430*1000	120
0.15	60	18	0.75	1300*600*1080	250
0.3	120	15	1.5	2270*750*1930	450
0.5	200	15	1.5	2350*800*2300	550
1	400	12	2.2	3050*1650*2700	850
1.5	600	10	3.0	3343*1650*2980	1020
2	800	10	4.0	3820*1900*3480	2040
2.5 Contact Infomation Send Inquiry Company name:Yangzhou Nuoya Machinery Co., Ltd. Status:[Offline] [Send message] [Chat] Business contact:David Shi(Ms.) Telphone: Mobile: Fax: Area: Caribbean Region-Bermuda Address:158# Western of Shugang Road, JiangYang Industry Area
