Model:YZ78 series
YZ78 series frame-type Automatic Demoulding hydraulic press
1.Overview:
This series of hydraulic machines is designed and used in diamond cutter industry.there are a series of strong points,such as simple structure,easy to operate,safety protection,can be operated by two types of semi-automatic operation.
2.Characteristics:
a.With the functions of idle stroke fast speed, slow moving close to the workpieces.
b.High speed, high efficiency, low energy consumption.
c.There are the operation buttons before and after, and all actions controlled by Siemens PLC, the balanced wroking and low noise.
d.Equipt with the imported hydraulic parts, good durability.
e.Equipt with the imported electric elements,there are photo-electric safety device front and behind to provide safety and overtravel protection.
f.Integral structure of host machine and oil box,easy to install.
3.Main technical parameter table:
Item |
| Unit | YZ78-200T | YZ78-300T | |
Nominal Working pressure of hydraulic system | KN | 2000 | 2000 | ||
Max.Working pressure of moveable workbench | Mpa | 20 | 22 | ||
Max.travel distance of moveable workbench | mm | 160 | 160 | ||
Max.distance between workbench and upper beam | mm | 380 | 380 | ||
Speed of speedy lifting of workbench | mm/s | 180 | 150 | ||
Speed of pressure lifting of workbench | mm/s | 2-4.5 | 1.8-4 | ||
Speed of speedy withdraw of workbench | mm/s | 150 | 180 | ||
Nominal pressure of material return tank | KN | 200 | 300 | ||
Expected to travel back |
| mm | 45 | 45 | |
Left-right | mm | 530 | 620 | ||
Effective area of workbench | forward-backward | mm | 510 | 650 | |
Flow of hydraulic pump |
| L/min | 10-24 | 14-36 | |
Power of Motor | KW | 7.5(6*) | 7.5 | ||
Overall dimension(L-RxF-BxH) | mm | 1290x1000X1550 | 1360x1000X1700 | ||
kg | 3000 | 4000 | |||
Weight(Apporx) |
4.We offer customized design according to your specific requirements with best cost-effective ratio.
