Frame Installation Dimension

2016-10-25 16:37 Views:112

Price:Negotiable

frame INSTALLATION DIMENSION

Model JA frame installation dimension table

Model JB(79standard) frame installation dimension table

type and siaes of reduction machine and frames fitted in with enamel reaction cylinders

specification of reciction cyclinder(liter)	model and soecification of reduction machine	type of reduction machine	frame model fittde		11	17	23	29
specification of reciction cyclinder(liter)	model and soecification of reduction machine	type of reduction machine	frame model fittde		130	85	63	50
50-100	BLD1-1-0.75	B11	JB1	Y802-4-0.75	0	0	0	0
200	BLD11-1-1.1	B11	JB2	Y90S-4-1.1	0	0	0	0
300-500	BLD13-1-3	B13	JB3	Y100L2-4-3	0	0	0	0
1000-2000	BLD131-1-4	B13	JB4	Y112M-4-4	0	0	0	0
3000	BLD13-1-5.5	B13	JB5	Y132S-4-5.5	0	0	0	0
5000	BLD14-1-7.5	B14	JB6	Y132M-4-7.5	0	0	0
