China Crushers, Rock Crushers
China Sand Making Machine with features of high-efficiency andenergy-saving, which designed by our professional engineers, absorbing theadvanced techniques of the same products, plays an important role in crushing machinery.
This series sand making machine product is widely used in crushing various kinds of mine, cement, fire-proofmaterial, corundum, glass raw materials, building sand, stone materials, andother metallurgical slag. It is especially efficient to crush harder materials,such as carborundum, corundum, and magnesium sand, better in capacity than ofother crushers.
Sand Making Machine Specification:
| Model | Max. feeding (mm) | Power(Kw) | Impeller speed (r/min) | Output (t/h) | Outer dimension :L×W×H (mm) | Weight(T) |
| PCL-600 | 26 | 2×30 | 2000/2600 | 8-50 | 3000×1500×2050 | 5.4 |
| PCL-600B | 26 | 2×30-45 | 2000/2600 | 8-50 | 3000×1500×2050 | 5.8 |
| PCL-750 | 35 | 2×45 | 1500/2500 | 25-55 | 3300×1800×2440 | 7.3 |
| PCL-900 | 30 | 2×55-75 | 1200/2000 | 55-100 | 3600×2140×2620 | 12.1 |
| PCL-900B | 40 | 2×75-110 | 1000/1450 | 65-150 | 3600×2140×2620 | 13.6 |
| PCL-1050 | 40 | 2×90-110 | 1000/1700 | 100-160 | 4480×2450×3906 | 16.9 |
| PCL-1250 | 40 | 2×132 | 950/1200 | 100-200 | 4520×2640×3100 | 22 |
| PCL-1350 | 60 | 2×220 | 800/1200 | 160-360 | 5300×2900×3200 | 26 |
Note: This specification is just reference, any changes are subject to the products.
