Model:LWZ-D550x550/1500KN NO:150T UNIT
Send Inquiry
RUBBER INJECTION TRANSFER MOLDING MACHINE (150T)UNIT
Detailed goods description: for LWZ-D550x550/1500KN 150T UNIT.
| CLAMPING FORCE | 1500KN |
| SYSTEM PRESSURE | 21MPa |
| CLAMPING STROKE | 300mm |
| FAST CLAMPING SPEED | ≥60mm/s |
| HEATER PLATEN SIZE | 550×550mm |
| HEATER PLATEN DISTANCE | 200-500mm |
| MAX TEMP | 250 |
| EJECTOR TONNAGE | 60KN |
| EJECTOR STROKE | 300mm |
| TRANSFER STROKE | 435mm |
| TRANSFER PRESSURE | 110Mpa |
| HOPPER SPECIFICATION | 90×285mm |
| INJECTION WEIGHT | 1844cc |
| MOTOR POWER | 11KW |
| HEATER POWER | (6+6)KW×2 |
| OIL TANK CAPACITY | 400L |
| EXTERNAL DIMENSION | 3100mm×1900mm×(2900-3200)mm |
| WEIGHT | 8.5T |
Features: with SIEMENS or MITSUBISHI PLC controller, easy to operate. the moving platen protects the mould and raise production efficiency
rubber injection moulded products:
automobile parts(shock absorber), Rubber Gasket, Rubber Bumper, Rubber Dust Cap, Rubber O Rings, Rubber Couplings, Rubber Washers, Rubber Seals, Rubber Grommets.construction(rubber mat), medical equipment(stoppers for glass utensils) as well as Rubber Boots, Rubber Bellows
