Handkerchief Folding Machine (ZYJ-210-V)
2016-10-25 16:26 Views:58
Price:Negotiable
Model:ZYJ-210-V
Send Inquiry
Product name: Handkerchief Folding Machine
Product introduction:
ZYJ-210-V Handkerchief Folding Machine is the processing equipment for the production of standed or pocket-sized handkerchief. The machine adopts vacuum absorption folding and frequency speed controlling. It is easy for operation and makes neat folding results.
|
| Technical parameters: | | Parent roll | 13-20g/ two layers, 23-25g/ single layer tissue paper | | Parent roll core | 3(Dia.76mm)(other sizes to be ordered) | | Parent roll diameter | Dia.1200mm(other sizes to be ordered) | | Sheet size | (210×210)mm±2mm | | Folding size | (105×55)mm±2mm(standard);(75×55)mm±2mm(mini type) | | Folding system | Vacuum absorption | | Controlling system | Frequency speed controlling, Electric-eye inspecting | | Production speed | 600-800 sheets/min(speed differs according to different parent roll) | | Installed power | AC380V 50HZ 4KW(motor) 5.5KW(vacuum pump) | | Air pressure | 0.5Mpa(prepared by the purchaser) |
|
