Standards
Design and Manufacture:           Cast steel gate valve to API 600  or API  6D, ANSI B16.34
Inspection and Test:                    API 598
End Flanges Dimension:           ANSI B16.5
BW End Dimension:                    ANSI B16.25
Face to Face and End to End:   ANSI B16.10

Available Options
Size:                            2" ~ 48" (DN50 ~ DN1200)
Pressure Rating:     150lb ~ 2500lb (PN1.6 ~ 42MPa)
End Connection:      Flange Raised Face, Butt Weld, RTJ
Seat Rings:               Threaded(Renewable), Welded
Operation Type:        Handwheel, Gear, Electric, Pneumatic, Hydraulic
Body Material:           WCB, WC1, WC6, WC9, LCB, LCC, LC3, C5, C12, CF8, CF8M, CF3, CF3M, CF8C
Trims Material:         13%Cr, 304, 304L, 316, 316L, 321, 347, F-51, Monel
