hardware packing machine manufactory
main produce of hardware packing machine . automatic hardware packaging  machinery. hardware wrapping machine.
I. hardware packing machine ALD-250B Main performance and structure features

1. Double transducer control, flexible bag length cutting, operator needn’t to adjust the unloading working, saving time and saving films.
2.  human-machine operation, convenient and quick parameter setting.
3.Self diagnosis failure function, clear failure display.
4. High sensitivity optical electric color mark tracking ,digital input cut position which makes the sealing and cutting more accurate.
5. Separate PID control to temperature, suitable for various packing materials.
6. Stopping the machine in selected position, no sticking to the knife and no waste packing film.
7. Simple driving system, reliable working, convenient maintenance.
8. .All the controls are achieved by software, convenient for function adjusting and upgrading.

II. Application of hardware packing machine ALD-250B

Suitable for packing regular objects such as biscuit, bread, instant noodle, moon cakes, industrial parts, paper box or trays.


III. Optional device of hardware packing machine ALD-250B

1. Code applying machine
2. line sealing wheel
3. Moire terminal sealing mould
4. Extra big screen



Model

ALD-250B

ALD-250D

ALD-250S

Film width

  Max.250mm

Max.180mm

Bag  length

  65~190mm Or 120~280mm

90~220mm

45-90mm

Bag  width

 30~110mm

30-80mm

Product height

 Max. 40mm

Max. 60mm

Max.35mm

Film roll diameter

  Max.320mm

Packing speed

  40~230 pack/minute

60-330bag/min

Power supply

  220V,50/60HZ,2.4KVA

Size

  (L)3770X(W)670X(H)1450

Weight

  800Kg

note



fill  gas
