Film Blowing and Offset Press Unit
2016-10-25 14:56  Views:125
Price:Negotiable
Model:SD-45-YT2600, SD-55-YT2800, SD-60-YT21000
Send Inquiry

Name: Film Blowing and Offset Press Unit (SD-YT Series)

The fuselage is a square steelchassis, drags elsctric motor taking frequency conversion, friction to collect a book only, going up and down and so on.

Be fit to puff height, low pressure polyethylene industry film, farm-oriented mulch film. Continue printing the various platic film, spread and despise the leather, package products, shan two-sides pritingonce to be completed. 360 degree of register sets, not affecting the film elongating by accurately, can make to print adjustment, the image are at any time arbitrarily limpid to the color exquisite.

Main technical parameters:
ModelSD-45-YT2600SD-55-YT2800SD-60-YT21000
 suitable materialLDPE,HDPE,LLDPELDPE,HDPE,LLDPELDPE,HDPE,LLDPE
Screw  ratioL/D28:1L/D28:1L/D28:1
driving  motor11Kw15Kw18.5Kw
Max.extrusion output36kg/h50kg/h70kg/h
die sizeÓ60 Ó80Ó80 Ó130Ó80 Ó160
width of Blowing film 600mm800mm1000mm
 thickness of Blowing film 0.008-0.10mm0.008-0.10mm0.008-0.10mm
Printing length scope191-1200mm191-1200mm191-1200mm
Printing width560mm760mm960mm
Total power28kw32kw40kw
Machine weight3800Kg4200Kg5000Kg
outline diameter(L*W*H)6000*2400*40006200*2600*43006400*2800*4800
