Model:149
Send Inquiry
| Product Spec: | |
| Pitch: | 1.00mm |
| Type: | Power connector |
| Number of Rows: | Single row |
| Mount type: | Straight |
| Number of contacts / pins: | 02-100 pins |
| Orientation relative to PCB: | Straight |
| Material: | |
| Contact Mateial: | Copper Alloy |
| Standard insulator material: | Polyamide PA6T , UL94-V0 |
| Optional insulator material: | Polyester LCP, UL94-V0 |
| Nylon 6T suitable for: | IR Reflow, Wave, Manual solder |
| LCP suitable for: | IR Reflow, Wave, Manual solder |
| Plating: | |
| plating | Au or Sn over 50u" Ni |
| Contact | brass |
| Contact Plating: | Gold Flash |
| Electrical: | |
| Current Rating: | 1AMP |
| Operation temperature: | -40°C to +105°C |
| Contact resistance: | 20m Max. |
| Insulation | High Temperature Thermoplastic UL94-0 Rated |
| Dielectric withstanding voltage: | AC 300V |
1) Minni jumper connector
2) We can change the qualifications according to your demands
3) Single row
4) Double row
