Model No.:XF5-113
Product Origin:China
Brand Name:Sixian
Price Terms:
Payment Terms:L/C, T/T
Certification:ISO9001
Description:XF5-113 revolving buckled cable distribution box with terminal is mainly appliedfor junction between the main cable and distributing cables in local cable networks;and is acceptable for aerial, ground or hanging installation. Features: Adopting a revolving buckled airtight mode of connection, this product is ensuredof stable and firm core contact without exposure to the outside and oxidation afterlong time use. The contact is safe and reliable by applying organic silicongrease for waterproofing and moisture sealing. Four basic units each of 25 pairs form the 100-pairs module. The positive and reverseconnection terminals of the module are arrayed on the basis of YD322 chromatogramstandard and printed with clear and full marks, which are convenient for jumperingand maintenance. The module unit line bank may turn around different Y-axes and open at an angle ofmore than 90 degrees, ensuring easy connecting of the main and distributing cables.The rubber sealing strips applied to the seams of doors and around the box effectivelykeep the rainwater out. The rubber sealing ring applied to the cable entrance holeat the base of the box prevents underground humidity from entering. The box is made of top quality cold rolled plate, stainless steel or aluminum alloysprayed with pure resin. Its protective properties are up to the GB4208 standard.
