Item Number: XF001
Product Name: PEX-B Cross-linked Pipe
Specification:GB/T18992.2-2003                                               Φ12/16mm - wall thickness 2mm
Φ14/18mm - wall thickness 2mm
Φ16/20mm - wall thickness 2mm
Description:

1, Good performance in nominal pressure at 1.25MPa

2,Φ12/16mm burst pressure≥ 6MPa, Φ16/20mm burst pressure≥5MPa
3, High temperature, low temperature performance is superior(-70-95℃ short110 ℃)

4, Acid resistant & corrosion resistant, allowed for multiple chemical transporting.

5, Pipe wall is smooth, low resistance without fouling. Really clean, no pollution

6, Be installed quickly and easily without tapping, buckle sets, welding

7, Light weight & Easy to bend flexibility, saving fittings,
8, Good thermal insulation & warm keeping properties

9, Long life-span of 50 years in 70℃& working pressure≤0.8MPa
Application: Under-floor heating, Hot and cold cycle system, other related, etc.
Packing: 180/200m per roll wrapped PE films outside
