Model:ZC-68Y/Y3, LC-80Y/Y3
Send Inquiry
- MODEL ZC-68Y ZC-68Y3 LC-80Y LC-80Y3 ZC-68Y with bracket LC-80Y with bracket
- AIR DISCHARGE side side side side side side
- MAX. AIRFLOW(cmh) 6800 6800 8000 8000 6800 8000
- APPLICABLE AREA(m2) 20-50 20-50 30-90 30-90 20-50 30-90
- MAX. AIRPRESSURE(Pa) 45 45 50 50 45 50
- NOISE(dB) <55 <55 <60 <60 <55 <60
- POWER SUPPLY(V/Hz) 220/50 220/50 220/50 220/50 220/50 220/50
- POWER(KW) 0.2 0.2 0.3 0.3 0.2 0.3
- FAN MOTOR Axial Axial Centrifugal Centrifugal Axial Centrifugal
- WINDING DISTANCE(m) 8 8 12 12 8 12
- WATER STORAGE CAPACITY(L) 40 190 40 190 40 40
- BODY SIZE(m) 0.85X0.5X1.1 0.85X0.5X1.61 0.85X0.5X1.1 0.85X0.5X1.61 0.85X0.5X1.1 0.85X0.5X1.1
- PACKAGE SIZE(m) 0.87X0.52X1.12 0.87X0.52X1.38 0.87X0.52X1.12 0.87X0.52X1.38 0.87X0.52X1.12 0.87X0.52X1.12
- NET WEIGHT(KG) 37 48 43 51 37 43
- GROSS WEIGHT(KG) 40 51 46 54 40 46
- LOADING QTY(20'/40'/40HQ) 46/96/96 31/64/96 46/96/96 31/64/96 46/96/96 46/96/96
