Model:DK7780
Send Inquiry
Technical parameter of Wire-cut EDM Machine:
| the maximum stroke of the worktable(mm) | 1160x900 |
| the maximum length of workpiece(mm) | 1250 |
| the maximum width of workpiece(mm) | 800 |
| the range of the stroke between the two frames (mm) | 220~950 |
| the maximum of open-shelf height between the two frames(mm) | 950 |
| the maximum manipulation thickness(mm) | 920 |
| the maximum load capacity of the worktable(Kg) | 2800 |
| Weight OF Wire-cut EDM Machine(Kg) | 4800 |
| Size of Wire-cut EDM Machine(mm) | 2810x2670X2100 |
