The water cooling conveyer is an auxiliary machine of the Precision Preformer to avoid stickiness and deformation of the rubber blanks. After cooling down with cooling water or cooling solution, and then with forcible cooling wind, the rubber blanks will become dry and solid. The feature of the machine is that the running speed can be adjusted by the stainless steel net curtain during the whole process, to go with all the cutting speeds of the preformer.

Item:LSS650

Conveying width (Mm):450

Conveying length (Mm):9000

Ascending angleA?:40A?

Conveying speedhorizontal (M/min):
 0-10(Infinite speed regulation)

Conveying speedslopeM/min:
 0-10(Infinite speed regulation)

Water tank dimension(Mm):1400*800*270

Overall dimension(Mm):2500*900*1700

Motor power (W):2600
