The parameter
Tolerance Comparison | ||||
OD | GB/T3639 | DIN2391(EN10305) | Enterprise Standard | Special Range |
4mm-30mm | ±0.10mm | ±0.08mm | ±0.05mm | ±0.02mm |
31mm-40mm | ±0.15mm | ±0.15mm | ±0.05mm | ±0.03mm |
41mm-50mm | ±0.20mm | ±0.20mm | ±0.05mm | ±0.03mm |
51mm-60mm | ±0.25mm | ±0.25mm | ±0.08mm | ±0.03mm |
61mm-70mm | ±0.30mm | ±0.30mm | ±0.10mm | ±0.05mm |
| ||||
Thickness Tolerance | ±0.12mm | ±0.10mm | ±0.05mm | ±0.03mm |
the regular size:
28*2mm ,27.2*1.5mm ,30*2.5mm ,18*1mm,15*1mm,22*1mm
