Main performance WH09J type WH09JT type WH09JK -
Rated power A 0.1W other: 0.05W (50 ° C)
Maximum use of voltage DC 50V
Resistance area and the deviation 470 Ω ---- 1 megohms ± 20%
Resistance of A, B, C
Terminal resistor R <50K ohms 20 Ω Max R ≥ 50 K ohms 50 Ω Max
Rotational noise ≤ 47 mV
Synchronization error (double-type) ± 3dB within the (-40 --- 0 dB)
Rotating torque 2 - 12 mN.m
Axial force - Thrust 1 - 4 N
Switches torque 2 - 50 mN.m
Total machinery itinerary 300 ° ± 10 °
Mechanical Durability 10,000 Circumference Cycles
