Toyota Intelligent Tester3

1 LEXUS TOYOTA diagnosis and test
2 Read and clear codes
3 ECU ,KEYS Programming
4 Access to immobilizer

Description:

 ALLSCANNER® AS800ALSCAN (VCX® interface) offers a superset of ALSCAN2534 functionality. It supports standard PassThru communication, plus hosts applications internally, plus adds two protocols, plus extra voltages needed for ECU reprogramming, wireless Ethernet, or GPS modules.

Standalone operations

ALLSCANNER runs it’s own operating system which allows it to be used as a standalone tool without a PC attached during operation.

Customers Applications

1.        J2534 Independent Repair Facility tool

2.        Diagnostics using 3rd party applications

3.        In-vehicle pass-thru data logging

4.        Standalone data logging or monitoring

5.        Fleet or public transportation data acquisition

6.        OEM Engineering

7.        OEM calibration reprogramming

8.        End-of-Line testing

9.        Dealer Service Tools

10.    3rd party integrated solutions

11.    Specialized Customers

Hardware VCX® interface

CPU: 16 digit Dual Cell specialize CPU

RAM: 64KB RAM

FLASH: 256KB FALSH

Diagnostic Port: 24PIN, self-determination design

Wireless Port: 802.11b/g WIFI wireless

LED: 4 LED indicators light, indicate power and status.

Power: DC 9V-28V

Consumption: 3W

Size: 156(L) x86(W) x35(H) mm

Working Temperature: -20 to +70degrees

StorageTemperature: -40 to 85degrees

J2534-2 Support

The EPA standard for independent shop reprogramming is J2534-1, but since automakers recognized that the J2534-1 standard did not cover all of their needs for the future. This leads to the development of J2534-2, a set of optional extensions. The ALLSCANNER® VCX® from AOTOTECH Technologies supports many J2534-2 extensions. Supported J2534-2 extensions include:

1. Single Wire CAN

2. CAN Mixed Mode

3. A/D Inputs

4. Pin Switching

Kindly Note: This package does NOT provide software applications. This is responsibility of the buyer. (Software Specification Vedix® is the latest diagnostic software platform of ALLScanner® to work with the hardware of VCX®,the characters be shown as below:
1. Diagnostic software can be operated under WinCE and Windows, available installation for Laptop or PDA.
2. Automotive Diagnostic language (VDL) exploitation platform based on XML by self-determination and high efficiency database management system, these will make it easily to explore the vehicles.

3.Continuously update for diagnostic software remotely.
