function and features:

1, 35mm standard DIN rail installation, complying with standard DIN EN50022. Or front board setting (mounting holes center distance 63 mm), users can choose any one by themselves..

2, Six pole width (Modulus 12.5mm), complying with standard JB/T7121-1993.
3, Standard configuration 5+1 digits display (99999.1kWh) by step motor and pulse machinery counter. May select 6+1 digits display (Product Configuration code is AK).
Standard configuration one port of pulse output passive (polarity), May select increase a distant port of pulse output passive (no polarity), (Product Configuration code is AI). And contact with all kind of AMR system conveniently, complying with standard IEC 62053-31 and DIN 43864.
4, Bicolor LED instructions power state (green) and signal of power impulse (red).
5,  Standard configuration dont detect direction of the trend of load current. May select Automatic Detecting the direction of the trend of load current. And instructions (only red power pulse signal when working, that is meaning the load current reverse).
6,Single direction measure single phase two wire active Power consumption. It is nothing with direction of the trend of load current. Complying with standard IEC 62053-21.
7,  Directly connect and use, there are two types you may select. Standard configuration type S connection, may select type T connection (Product Configuration code is TG).
8, Standard configuration extended terminals cover, in order to protect to use electricity safely, may select short terminals cover. (Product Configuration code is AH).
