NISSAN UD DIESEL Dump Truck 6x4 Series-CSC3430GPT

EXCELLENT  Point:

Engine           New PF6,320HP,NISSAN original diesel engine

Transmission     MTS62,6 forward gears and 1 reverse gear

Axles             From Japan

Cabin             Painting guaranteed for 10 years,all the cabin accessories from Japan

Hydraulic jacking  HYVA from  Holand technology

Delivery time      25 workdays

MODEL       CSC3430GPT

Chassis       UD310CWB

Drive System    6X4

SIZE  (common cargo box)

Dimension(mm)   7530x2490x3240

Cargo Size(mm)   5068x2180x1500

Wheelbase(mm)   3200+1300

WEIGHT   　

G.V.W(kg) 43000       Payload(kg)        31000        G.C.W (kg) 12000

ENGINE   & TRANSMISSION

Engine Type     PF6 DIESEL ENGINE(6 cylinder in-line with water cooling, turbo-charging )

Max Power(kw)  235      Emission(ml)  12503        Emission   Euro 2

Gearbox          MTS62, 6 forward gears and 1 reverse gear

Cabin               Nissan cabin(Painting guaranteed for 10 years)

TIPPER SYSTEM      　

Loader Material            Q235A Carbon Steel(WISCO)

Side Plate Thickness(mm)             6

Bottom Plate Thickness(mm) 8

Oil Cylinder       HYVA 191 oil cylinder T-type hydraulic lifting system.

CSC TRUCK is proud of Professionalism Reliability and Commitment to ensure the success of your overseas purchasing program and your Project

Feel free to contract CSC Bruce for more details.(Specification,Photo or up-to-date Price)
