capsule ball has good wear-resistance, low wear, broken rate is only two thousandth, not deformation, long life cycle etc
name:low chrome alloyed capsule ball
Chemical composition<%>
C | Si | Mn | Cr | Mo | Cu | S | P |
1.8-3.2 | 0.5-1.5 | 0.4-1.5 | 0.8-3.5 | 0-0.6 | 0-0.6 | 0.15 | 0.15 |
Mechanical properties of products
Microstructure | Toughness without Notch < J/cm2> | Hardness<HRC> |
P+C | 1.5 | 4550 |
P-Pearite C-Carbide | ||
Specification and Weight
Specification | Weight<kg> |
φ30×60×39×16 | 0.28 |
φ34×68×51×16 | 0.46 |
φ42×84×63×26 | 0.75 |
φ48×96×73×30 | 1.25 |
φ57×114×83×34 | 2.0 |
φ64×128×89×36 | 2.5 |
φ72×144×99×44 | 3.95 |
φ79×158×109×44 | 5.22 |
φ86×172×119×48 | 6.75 |
φ90×125×90×47 | 5.1 |
