Model:JG-13090 DT
JG-13090 SG LED Light Guide Panel Cutting Machine,LED Light Guide Panel Laser Cutting Machine
Product Feature
1.Extensive working range, large working area
2.Adopts personalized auto up-down working table which meets the requirements for processing different area materials
3.Ensures the best focus and processing effect of different thickness materials
4.Equipped with rotary device to do fine engraving on wood , bamboo ,etc, various non-metal tubular materials.
Application Field
Applicable Materials: Wood, Plywood, Bamboo, MDF, Balsa, Veneer Inlays, Acrylic, Acryl, PMMA, Perspex, Plexiglas, Plexiglass, Organic Glass, Rubber Sheet, Plastic, Industrial Plastics (PP, PE, PET, PVC, ABS, PA, PS, PC, etc. ), Paper, Corrugated Paper, Cardboard, Pressboard, Paperboard, Chipboard, etc.
Applicable Industries: Advertising Industry, Advertising Signs, Plastic Industry, Printing & Packing Industry, LED LGP Panel, Gifts & Crafts, Promotional Items, Plaques, Trophies, Awards, Bangles, Badges, Tags, Decorations, Souvenirs, Precise Ornaments, Model Toys, Architectural Models, Furniture Interiors, Wood Floors, etc.
Technical Parameter
Laser type | Hermetic and detached CO2 laser tube |
Laser power | 80W(JG-13090SG) 80W×2(JGSH-13090SG) |
Cutting area | 1300mm×900mm |
Cutting table | Zinc honeycomb working table |
No-load max speed | 0-24000mm/min |
Repeating location | ±0.1mm |
Moving system | Offline stepping control system |
Power supply | AC220V±5% / 50HZ |
Format support | AI,BMP,PLT,DXF,DST etc |
Standard collocation | 550W up & down exhaust fan, mini air compressor |
Select collocation | Hermetic and detached CO2 laser tube(65W/100W),Auto focus system,rotary engraving system,automatic control high pressure blower valves, constant temperature water-chiller,strip panel working table, servo system |
