Specification:

★Power supply:6V (4 AAA batteries)
★Static state current:≤80 A
★Alarm reporting state current:≤100mA
★Monitor speed range:0.1m/s ~ 4 m/s
★Monitor coverage range:12m /120 degrees
★Installation high:2 ~ 2.5 m
★Alarm reporting type:wireless output
★Transmitting distance:≤500m(In open area)
★Transmitting frequency:315MHz
★Operation temperature range:-10 ~ 50oC
★Anti-radio frequency interference ability:1GHz 20V/m
★Size:91cm×61cm×46cm(Excluding antenna)

Funcation:

★High accuracy passive infrared detector
★Signal with energy accumulative logic processing, and random dynamic
time partition processing
★Three levels of sensitivity (high/medium/low)
★Low pressure detection and alarm reporting
★High capability of preventing radio frequency interference (Match CE
standard) via SMD wiring
★Insensitive to the white and the closed shell preventing the system
damaged
★Automatic temperature compensation and self-diagnostics
★Stable and reliable performance, and easy installation
