SPECIFICATIONS
| Basic Functions of Insulation Resistance Testers | Range | Best Accuracy | |||
|---|---|---|---|---|---|
| Insulation Resistance | 0.5MΩ ~100GΩ | (3%+5) | |||
| Testing Voltage | 500V/1000V/1500V/2500V | 0~20% | |||
| DC Voltage | 600V | (2%+5) | |||
| AC Voltage | 600V | (2%+5) | |||
| Special Functions of Insulation Resistance Testers | |||||
| Auto Ranging | |||||
| Short Circuit Current | <1.8mA | ||||
| Data Logging | 18 | ||||
| Data Recall | |||||
| Sleep Mode | |||||
| Polarization index (PI) | |||||
| Dielectric Absorption(DAR) | |||||
| Timer | Around 15 minutes | ||||
| Compare | |||||
| Battery Display | |||||
| White Display Backlight | |||||
Over Range and High | |||||
| USB | |||||
| Max. Display | 9999 | ||||
| Analogue Bar Graph | |||||
| Power of Insulation Resistance Testers | 1.5V Alkaline Battery(LR14)×8 |
| LCD Size | 123 mm x 58 mm |
| Product Color | Red and Grey |
| Product Net Weight | 1.8Kg |
| Product Size | 202×155×94mm |
| Standard Accessories | 2 pcs of one plug test lead to one alligator clip (black and Green), 1pc of two plugs test lead to one alligator clip (Red), Batteries, English Manual , Tool Box, USB Interface Cable, Software |
| Optional Accessories* | Power Adapter |
| Standard Individual Packing | Gift Box |
| Standard Quantity Per Carton | 4 pcs |
| Standard Carton Measurement | 525 × 335 × 345mm (0.061 CBM Per Standard Carton) |
| Standard Carton Gross Weight | 18kg |
*Available at Extra Cost Specifications and other information of Insulation Resistance Testers are subject to change without further notice. |
