Contact NO.: 0086 13917145176     Contact Name: Judy

Brand:  KATO

Mode:NK500E

Capacity:50T

Year: 2002

Engine and Chassis: NISSAN

Condition: Excellence working condition

Boom Length:10.8m-40.0m (5 sections)

Fly jib length:9.2m-15.0m (2 sections)

Max rated lifting capacity:50.5T*3.0m

Max lifting height:29.8m(boom)

Slewing speed:2.4rpm

Boom extending time:132 sec.(10.8-40.0)

Hoisting line speed:

Main wich: 115m/min

Auxiliary wich:100m/min

Main winch:Type: 4*F(40)(Non-rotating type)

Diameter:18mm

Length:180m

Auxiliary winch: 4*F(40)(Non-rotating type)

Diameter:18 mm

Length:120mm

Oil pump:4 section geart type

Max traveling speed:80km/h

Min turning radius:11.5m

Dimension(mm):13300*2750*3800

Wheel base(mm):1450+3850+1350=6650

Treads:Front:2240 mm

Rear:2055 mm
