Rate frequency(Hz)

50 60

Rated voltage(V)

230 240

Rated current(A)

7.4 7.8

Rated output power(kW)

1.7 1.8

Rated rotation speed(rpm)

3000 3600

Welding voltage at zero load(V)

65

Rated welding DC current(A)

160

Rated voltage(V)

26~30

Welding load continuous ratio

40%

Current rectorgulation range(A)

50~180

Power factor(cos)

1.0

Phase number

Single phase

Noise level[dB(A)@7m]

74~77

Overall dimension(L*W*H)[mm(in)]

720x492x650(28.35x19.37x25.60)

Dry weight[kg(ibs.)]

102(224.4)

Structure type

Open-frame type

Continuous running time(at rated load)

12hours

Excitation mode

Self-excitation and constant voltage(AVR)

Starting system

12V electric starter

Engine model

186FE

Engine type

Single cylinder, 4-stroke, air-cooled,  direct injection, diesel engine

Displacement[ml(cu.in)]

406(24.78)

Compression ratio

19:1

Rated power[kW(HP)/rpm]

5.7(7.75)/3000,6.3(8.57)/3600

Fuel

SAE10W30(Above CC grade)

Lube

0#or-10#light diesel oil

Fuel tank Capacity[L(gal.)]

12.5(2.75)

Lube Capacity[L(gal.)]

1.65(0.36)

Low oil prssure alert system

With
