Adopt color 1/3" sony  Super HAD II CCD
horizontal resolution reach 420TV
white balance adjustable
effectively increase DVR'S HDD storage space
Large-scale operation voltage, AC220V optional
Industrial design and production, precise circuit & structure
Easy for installation, nice streamline design

MODEL:RJ-2038
Horizontal Resolution 420TV Lines
Electronic Shutter PAL=1/50 ~1/100,000 sec, NTSC=1/60 ~1/100,000 sec
Pixel 420 TV Lines PAL: 512×582,NTSC: 512×492(H×V)
Scanning System   PAL/NTSC
Minimum Illumination:0.1LUX/ F1.2
S/N Ratio  "≥48dB
Video Output  "1.0Vp-p/75Ω
Acutance Control: "OFF/LOW/MIDDLE/HIGH
AGC:ON/OFF
White Balance:ON/OFF
Backlight Compensation: ON/OFF
Gamma Correction:0.45
Exposure Mode:EE
Color Repression: ON/OF
Lens Driver:"Video/DC Switchable
"
Sync.System:Internal Synchronization
Voltage Input :DC12V±5%
working temperature:-10℃ ~ +50℃
Working humidity :10% ~ 85%
Net weight:270g
