Model:(MW9020)
Send Inquiry
Woodworking round rod machine most used for square wood into round shape.
Wood rod miller machine provided with heavy-duty construction, and quickly produces round rods from square stock
This round rod milling machine also provide with two-speed automatic feed and 2 Magnetic safety switches.
Various cutters and feed rollers of this woodworking round rod milling machine to accommodate different sizes and types of stock including: Acrylic, rattan, bakelite and wood. One piece cast iron base for machine.
| Model | MW9020 |
| Main motor power | 2.2 kw (3HP) |
| Feeding motor power | 0.55 kw (3/4HP) |
| Spindle velocity | 5000 r/min |
| Feeding speed | 3-5 m/min (Double Pully Gear ) |
| Cutting diameter | 6mm-20 mm (1/4" ) (select squar section material) |
| Max chipping allowance | 1 mm (semidiameter) (1/25" ) |
| Min cutting length | 300 mm(11-4/5" ) |
| Overall dimension | 720× 560× 820 mm |
| Machine weight | 170 kg |
