Products Name:Screw Air Compressor XAS97 (XAS185)
1.Compressor data:XAS97 (XAS185)
2.Free Air Delivery @ Normal Working Pressure:89 L/S (5,3 m³/min )
3.Normal Working Pressure:7 bar
4.Minimum / Maximum Unloading Pressure:4 / 8.5 bar
5.Compression Stages:1
6.Air Receiver Capacity:16.7L
7.Compressor Oil Capacity:8 L
8.Approximate Air Outlet Temperature:90°C (Standard)
9.Typical oil content of compressed air:<5 mg/m³
10.Fuel Tank Capacity:80L
11.Outlet Valve Configuration:3 x 3/4” G, 1 x 1.5” G
12.Nominal working condition:Inlet pressure 1bar,Humidity0%,Temp20 °C
13.Sound Pressure Level (ISO2125):72 dB(A) +/- 3
14.Maximum Ambient Temperature at sea level:45 °C
15.Maximum Altitude:5000 m
16.Minimum Starting Temperature:-10 °C / -20 °C (with assist)
17.Diesel Engine data:DEUTZ F3M2011
18.Horsepower Developed @ Rated Speed:36 kW
19.Cylinders:3
20.Cooling System:Oil
21.Engine Coolant Capacity:--
22.Engine Oil Capacity:8.5 Liter
23.Unloaded Speed / Maximum Loaded Speed:1850 / 2750RPM
24.Fuel Consumption @ 0% Load / 100% Load:3.6 / 7.2 kg/h
25.Dimensions:Standard Towing Speed 20 km/h
26.Length:3016 mm ( within towbar )
27.Width:1410 mm
28.Height:1258 mm
29.Weight ( filled with oil & coolant , Initial fuel ):890 kg
