Characteristics:
--High strength aramid yarn strength member ensures tension-resistance and long term stability in transimisiion.
--Small outer diameter, lightweight, flame-retardant, easy to strip, low attenuation, physically soft.
--Direct interconnecting tight buffer cables and need no tie-in box or pigtail.
--Suitable for construction operation, and convenient for maintenance.

Application:
--Building to building interconnection; indoor distribution; pigtail of the instrument-type communication equipment, as the moveable connect line for patch cords and connectors.

Temperature range: 20° C~70° C

Fiber Counl: 1
Outer Diameter. D(mm) : 1.6; 1.8; 2.0; 2.4; 3.0
Norminal weight(kg/km) : 2.9; 3.2; 3.5; 5.0; 6.8
Max. Tension(N) Short-term 80; 80; 100; 100; 150
Long-term 40; 40; 60; 60; 80

Min. Bending Radius
Install 20D
Static 10D
Max. Crush Resistance(N/100mm² ) 500

Ordering Choice:
Simlemode/Multimode Cable
Options available for other colors
LZSH or PVC material
