Model:HL5000SE
Send Inquiry
You can click here and know more.
| Model | HL5000SE |
Type | Brushless Self-exciting 2-poles Single phase |
Voltage Regulator | Condenser type |
| Rated Frequency [Hz] | 4.2/4.5
|
| Rated Output [KVA] | 4.5/4.8 |
| Max. Output [KVA] | 3.0/3.3 |
| Rated Voltage [V] | 110,120,220,230,240,110/220,120/240
|
| Power Factor [cosΦ] | 1.0 |
| DC Output | 12V/8.3A |
Over current protector | Fuseless circuit breaker |
| Dry Weight [kg] | 165 |
Dimension: L×W×H [mm] | 920×530×740
|
| Engine Model | HL186FAG3E*
|
| Displacement [cc] | 418 |
| Bore × Stroke [mm (in.)] | 86×72(3.39×2.83) |
| Continuous Output [hp] | 7.7 / 8.6 |
| Starting System | Electric |
| Fuel Tank Capacity [L] | 14 |
| Lubricating Oil Capacity [L] | 1.65 |
| Noise level(Rated at 7m) | 70DBA/71DBA |
