1. Specification

Shaped: different type (Ring; Round; Rectangle; Arcor any other OEM size )

Size: up to client’s requirements, in mm

Coating: Ni-Cu-Ni; Zinc; Epoxy; without coating

2. Moderate temperature stability

NdFeB magnets lose -0.09 ~ -0.13% of Br/°C.

Their working stability is under 80°C for low Hci Neodymium magnets and above 200°C for high Hci NdFeB magnets.

3. Excellent strength value

High magnetic performance (Br: 11,000 to 14,500 GS, Hcj: 11,000 to 30,000 Oe, BHmax: 35 to 50 MGOe)

4. Advanced Technology

The choice of Strip casting and HDDR technology in our factory allows us to make high performance NdFeB of N52 possible. The standard properties, N33, N35, N38, N40, N42, N48, N50, N52 (M, H, SH, EH, UH)

5. Extremely resistance to demagnetization

The intrinsic coercive force is over 30,000 Oe, like N35EH and N38EH property. Maximum working temperature: 80 to 200 centigrade. Super strong magnetic force and high intrinsic coercive force and also with precise tolerance

6. Effective surface treatment

Surface treatments have been developed that allow them to be used in most applications. The treatments include Ni, Ni-Cu-Ni, Zn, Ag, Au and other special plating. They are good at anticorrosion.

7. Customized Neodymium Magnets

Most of our magnets are customized. They are produced for customers' specific using, like arc, tile, square, cylinder and magnetic ring with various sizes. Common specification samples will be available in stock for your testing first.

8. Feature

NdFeB Magnet Grades: N33, N35, N38, N40, N42, N48, N50, N52 (M, H, SH, EH, UH)

Coating: Ni, Ni-Cu-Ni, Zn, Ag, Au and other special platings and coatings

Shape: arc, tile, square, cylinder and magnetic ring with various sizes

High magnetic performance (Br: 11,000 to 14,500 GS, Hcj: 11,000 to 30,000 Oe, BHmax: 35 to 50 MGOe)

Maximum working temperature: 80 to 200 centigrade

Super strong magnetic force and high intrinsic coercive force and also with precise tolerance

9. Applications

1) Generators, servo motors, DC motors, computer rigid disc drives

2) Loudspeakers, annunciators, linear actuators, microphone assemblies

3) Magnetic separators, automatic mahjong machines

4) Toys and other industries and etc.
