1Pre-pressing paper feeding type, smoothly;
2Thin knife slitting, thickness of the blade: 1mm;
3Grind the blade edge with grindstone in two methods: automatically or manually;
4Sharp blade edge can slit the cardboard smoothly and neat.
5Work process: Pre-pressing, slitting and creasing. Creasing line without crack.
6The machine can be provided to corrugated paperboard production line.
| Parameter | Unit | Model | |
| BFY-2000 | BFY-2500 | ||
| Feeding width | mm | 2000 | 2500 |
| Max. speed | m/min | 150 | 150 |
| Slitting blade | piece | 3-5 | 3-5 |
| Min. Separate slitting width | mm | 200 | 200 |
| Min. creasing width | mm | 200 | 200 |
| External diameter of thin & round blade | mm | 260 | 260 |
| Thickness of thin & round blade | mm | 1 | 1 |
| Power | kw | 4 | 4 |
| Weight of machine | kg | 2000 | 2500 |
| Exterior dimension | mm | 2630x1791x1130 | 3050x1791x1130 |
