Brand:ZHONGDONG
Model:ST-01
Specifications
STEEL CORDConVEYOR BELTING
1,high tensile strength
2,small elongation
3,long service life
4,quality assurance
STEEL CORD ConVEYOR BELTING
| Standard belt specification | ||||||||
| Belt strength (st-NO.) | Max Cord diam (mm) | composition | Pitch (mm) | Standard working tension | standard cover Thickn | Belt weight(Kg/m2) | cord strngth KN/piece | |
| St-630 | 3.0 | K6x7+IWS | 10 | 90 | 5x5 | 19.1 | 800 | 6.93 |
| St-800 | 3.5 | K6x7+IWS | 10 | 110 | 5x5 | 20.6 | 800 | 8.8 |
| St-1000 | 4.0 | K6x7+IWS | 12 | 140 | 6x6 | 24.7 | 800 | 13.2 |
| St-1250 | 4.5 | K6x7+IWS | 12 | 175 | 6x6 | 25.4 | 800 | 16.5 |
| St-1600 | 5.0 | K6x19+IWS | 12 | 225 | 6x6 | 26.0 | 1000 | 21.12 |
| St-2000 | 6.0 | K6x19+IWS | 12 | 285 | 8x6 | 30.0 | 1000 | 26.4 |
| St-2500 | 7.2 | K6x19W+IWS | 15 | 355 | 8x6 | 32.2 | 1250 | 41.25 |
| St-3150 | 8.1 | K6x19W+IWS | 15 | 450 | 8x8 | 35.7 | 1400 | 51.98 |
| St-3500 | 8.6 | K6x19W+IWS | 15 | 500 | 8x8 | 44.9 | 1500 | 57.7 |
| St-4000 | 8.9 | K6x19W+IWS | 15 | 570 | 8x8 | 46.6 | 1600 | 66 |
| St-4500 | 9.7 | K6x19W+IWS | 16 | 645 | 8x8 | 49 | 1800 | 79.2 |
| St-5000 | 10.9 | K6x19W+IWS | 17 | 715 | 8.5x8.5 | 53.6 | 1800 | 93.5 |
| St-5400 | 11.3 | K6x19W+IWS | 17 | 760 | 9x9 | 57.5 | 2000 | 101 |
