Details of 354 with E MARK:

Engine

Model: TY395

Type: 3-cylinder,Upright inline cylinder radiator cooling,4-stroke cycle,direct-injection

Rated power(KW): 25.80KW ,35 HP

Rated rotation speed(r/min): 2400 rpm

Total Displacement(L): 2.23

Transmission

Speed range(km/h):

          Forward 1.74/2.80/4.40/5.92/9.02/15.54/22.85/30.68

          Reverse:2.26/11.70

Clutch:linkage type dual-function clutch

Differential: Bevel Gear

Differential Lock:Jaw Lock

Final Transmissions: Spur gear,External gearing

Tyre size(front/rear): 7.5-16/12.4-24

Steering Gear:Hydraulic steering

Brake:Disk type

Tractor

Wheel base(mm): 1739

Front wheel tread/Rear wheel tread(mm): 1200/1100(Ususlly use)1200,1300,1400

Ground Clearance(mm):Under Front Axle:358

                                   Under Rear Axle:378

Min.Turning Radius(m):2.80

PTO shaft rotating speed(r/min): 540/1000

Rated Traction(N): In Paddy Fields 5160

                                  In Dry Fields: 7230

Overall dimensions

LXWXH (mm): 3370 x 1500 x 1620(Height to steering wheel)
