QPJL link-plate chip conveyor is composed of transmission system, tensioning system, overload protective device, hinge joint link-plate conveyer belt, and main frame etc. Quality board is selected and stamped to be link-plate conveyer belt. Wearing and corrosive treatment is carried out to its main parts.

link-plate chip conveyor is applicable for various chips, such as steel chips, cast iron chips, copper chips, aluminum chips and nonmetal chips etc. It is widely applied to drilling, winding, lathing, planning and milling machines and modular machine tools. In addition, it can also be the conveying equipment of small work pieces. Different pitches are available, including 31.75mm, 38.1mm, 50.8mm, 63.5mm and 101.6mm.
