Automatic Magazine Loader ETA Details

 Microcomputer control, stable and reliable.

 LCD screen display, menu interface, the man-machine dialogue is convenient.

 Many sound-light alarm function.

 So can use standard feeder, strong commonality.

 According to the thickness of the PCB so set feeder lifting step distance.

 Under so feeder built-in push board institutions, avoid buy separate push trigger.

 Automatic counting functions, facilitate production statistics.

 Signal communication interface, and other machines online travel.

Specifications   Loader/Unloader
Loader Dimension(LxWxH)  1650x730x1250mm
Unloader Dimension(LxWxH)  2450x730x1250mm
Electric Supply Required  2phase,220V 50/60Hz                          Weight  Approx.230KG
Pitch Selection  10,20,30,40,50mm
Magazine Size  355x320x565mm
Power Consumption  240W
Max.Width Of PCB  300mm (Option:410mm )
Converyor Height  900+/-20mm
Air Supply  4.5-6Kg/cm2
