Lifting chain

2016-10-24 21:23 Views:259

Price:Negotiable
Model:chain

chains,lifting chains, hoist chains, alloy steel chain, manganese steel chain

We manufacture high quality lifting chains of various types, special specifications can be customized,too. Applications: Lifting chain, lifting beam, chain for hoists
Material: High quality alloy steel
Surface: Polishing, power coated black, hot-DIP galvanized, DIP painted, electro-galvanized, broil painted, plastic coating
Tension Grade: 80
Safety assurance: Min. Safety factor is 4, proof load is 2.5 times of SWL.

Specification(mm)	Width		Approx Weight(kg/m)	Working Load Limit(t)	Test Load(KN)	Breaking Load min. (KN)
Specification(mm)	Inside min.	Outside max.	Approx Weight(kg/m)	Working Load Limit(t)	Test Load(KN)	Breaking Load min. (KN)
6*18	7.5	21	0.79	1.1	27	45.2
7*21	9	24.5	1.07	1.5	37	61.6
8*24	10	28	1.38	2	48	80.4
10*30	12.5	35	2.2	3.2	76	125
11*43	12.6	36.5	2.33	3.8	92	154
12*36	15	42	3.1	4.6	109	181
12.5*38	15.5	42.2	3.3	4.9	117	196
13*39	16.3	46	3.8	5	128	214
14*42	18	49	4.13	6.3	150	250
14*50	17	48	4	6.3	150	250
15*46	20	52	5.17	7	168	280
16*48	20	56	5.63	8	192	320
16*49	24.5	59.5	5.71	8	192	320
16*64	23.9	58.9	5.11	8	192	320
18*54	23	63	6.85	10	246	410
18*64	21	60	6.6	10	246	410
19*57	23.7	63.2	7.7	11.3	270	450
20*60	25	70	8.6	12.5	300	500
22*65	28	74.2	10.7	15.3	366	610
22*66	28	77	10.2	15.3	366	610
22*86	26	74	9.5	15.3	366	610
24*72	32	82	12.78	18	432	720
24*86	28	79	11.6	18	432	720
26*78	35	91	14.87	21.3	510	850
26*92	30	86	13.7	21.3	510	850
30*90	38	105	19.6	28.3	678	1130
30*108	34	98	18	28.3	678	1130
32*96	40	106	22.29	32.2	772	1286
34*126	38	109	22.7	36.3	870	1450
34*102	46.5	121.5	25.5	36.3	870	1450
36*108	49.5	128.5	31	40.7	978	1630
38*137	42	121	29	45.3	1086	1810
38*114	52	136	32	45.3	1086	1810
42*126	55.5	144.5	38.6	55.4	1332	2200
