ABB RESIBLOC 24KV Resin-encapsulated dry type Transformer 100 2500KVA
Reduced no-load loss transforming 24 kV
Rated power kVA | Load loss at 120ºC W | Load loss at 75ºC W | No-load loss at 100% Ur W | Short-circuit Impedance % | Sound power Level dB |
100 | 2050 | 1750 | 460 | 6 | 59 |
160 | 2900 | 2500 | 650 | 6 | 62 |
250 | 3800 | 3300 | 880 | 6 | 65 |
315 | 4580 | 4000 | 1050 | 6 | 67 |
400 | 5500 | 4800 | 1200 | 6 | 68 |
500 | 6870 | 6000 | 1400 | 6 | 69 |
630 | 7800 | 6900 | 1650 | 6 | 70 |
800 | 9280 | 8100 | 1900 | 6 | 72 |
1000 | 11000 | 9600 | 2300 | 6 | 73 |
1250 | 13100 | 11500 | 2700 | 6 | 75 |
1500 | 16000 | 14000 | 3100 | 6 | 76 |
2000 | 19100 | 19000 | 4000 | 6 | 78 |
2500 | 23000 | 20000 | 5000 | 6 | 81 |
