Technical data:
1, Output torque: Top to 470000(N. M)
2, Rated power: 9-5082(kw)
3, Input speed: 1500 (rpm)
4, Output speed: 1-1200(rpm)
5, Transmission ratio: 1.25-450
6, Stage: 1-4
7. Size: 3-26

Description:
1. Same dimensions as FLENDER.
2. Parallel shafts, right-angled shafts, horizontal or vertical mounting modes, reduced components and increased models.
3. Motor connection flange or input shaft: Solid shaft with parallel key, hollow shaft with parallel key, hollow shaft with shrink disk, hollow or solid shaft with involute spliness, solid shaft with flange.
4. Foot-mounted, flange-mounted, swing base-mounted, torque-arm-mounted.
5. Obtaining larger ratio combined with R, K and S series
6. Through Carbonization, Quenching, Grinding technics With Niles, Okuma, Mitutoyo devices.
7. Save space, durable, high bear ability, the power can reach 5000kw.
8. Low consumption, superior performance, the machine efficiency is up to more than 93%.
9. Small vibration, low noise, high energy conservation.
10. ISO 9001 CE approved.
11.Install form: H/M/V Design
