Capsule：Ø12.7-190mm

Operating：0-500rpm

Current Rating：5/10/15amps per circuit

Voltage：380V AC/DC

Temperature Range：-40℃~ +80℃

Dielectric Strength：≥100VAC@50Hz Between each circuit

Resistance Fluctuate：≤8mΩ

Work Life：≥60000000rev

Insulation Resistance 1000MΩ@ 500VDC

Contact Material Precious metal

Lead Wire Size  Teflon® UL

Housing Material Aluminum alloy

Protection IP54 or higher
