Brand:huajian
Cable Pusher/Cable Laying Equipment is a kinds of power cables /communication cable electrical laying machinery.--huanjian power tools
It mainly consists of two motor, one reduction box traction head and up frame,etc.
It not only applied for traction power cable, communication cable and aerial wire, also for other tranction fields in the situation of cable duct, tunnel, direct-burried, long-distance transmisson. It has small volume light weight, strong thrust force ,easy to operate, so Iit can be used alone or coordinated with our company other conveying sets.--huanjian power tools
Model No. | Motor Power (KW) | Convey Diameter(MM) | Rated Force(KN) | Pull linespeed (M/MIN) |
DCS-3 | 0.75X2 | 40-140 | 3 | 8 |
DSC-5 | 1.1x2 | 40-160 | 5 | 8 |
DSC-5B | 1.5X2 | 40-180 | 8 | 8 |
Cable Diameter Max. Adjustable clamping force ≤2.7KN | ||||
Specification | DCS-3 | DSC-5 | DSC-5B | |
Dimension | 880x500X400 | 980x500X420 | 1018X500x420 | |
Weight(kg) | 168 | 198 | 208 | |
Power Supply | 380V | 380V | 380V | |
